A complete, self contained vertical platform lift.

The Genesis Enclosure Model is a vertical platform wheelchair lift that can provide access to up to 4343mm (171″). This style of vertical lift is an easy and cost-effective accessibility solution for public buildings or private residences and is suitable for indoor or outdoor installations.

The Genesis Enclosure has a lifting capacity 340 kg (750lbs). The components of this Genesis Vertical Platform lift consist of a factory manufactured enclosure walls, with integrated doors and gates, a drive mast, passenger platform and easy to use call stations and platform controls.

The Genesis can be customized with a variety of optional features to suit the needs of the user and building owner. The wall panels, doors and gates can be designed from an extensive variety of colors and finishes.

The Genesis Enclosure Model wheelchair lift is equipped with many standard features. Some of these features are listed below. For a more extensive list of features contact your local Garaventa Lift Representative or refer to the Genesis Design and Planning Guide .

Enclosure Frame/Panels (standard)
The frame is constructed of champagne colored anodized aluminum extrusions. The panels for the Enclosure Model are available in 16 gauge galvanized steel painted with fine textured Satin Grey finish.

Doors and Gates (standard)
The standard configuration for this model is a full size Garaventa Lift style door at the lower landing. The upper landing may be fitted with a gate or full height door.

Offset D Handle (standard)
The offset d handle is available on both Garaventa Lift style doors and gates.

Door Interlocks (standard)
The Garaventa Lift Mechanical Interlock is the standard lock used for two stop enclosure lifts that are equipped with Garaventa Lift doors and gates. The interlock is activated by the movement of the platform, the lock is monitored by the safety circuit to ensure the door or gate is properly locked.

Drive System (standard)
A choice of two Drive Systems:
a) Leadscrew Drive with a 2 HP Motor
b) Hydraulic Drive with a 3 HP Motor – Continuous Mains Power with Auxiliary Power System

Lifting Height (standard)
Seven different lifting heights to a maximum of 4343mm (171″).

Call Stations (standard)
The standard call station is frame mounted, keyless and operates with constant pressure rocker switches.

Platform Controls (standard)
Consist of a directional rocker switch with an emergency stop/alarm switch and is keyless.

Finishes (standard)
The standard finish is anodized champagne aluminum frames, with steel panels that are powder painted in Moon Silver (fine textured finish).

Manual Emergency Lowering – Hydraulic Model Only (standard)
To lower the lift a knob can be pulled to manually open the valve and lower the platform.

Manually Emergency Lowering Handwheel – Lead Screw Only (standard)
A handwheel is attached to the lift and is used to manually move the platform to the desired landing in case of a power outage.
